Optimal Angiographic View for Implantation of Self-Expanding Transcatheter Aortic Valves

Cover Page


Cite item

Full Text

Open Access Open Access
Restricted Access Access granted
Restricted Access Subscription or Fee Access

Abstract

Background. Transcatheter aortic valve implantation is safe and effective alternative to surgical treatment of severe aortic valve stenosis among patients of all risk groups. Optimal implantation depth is key for successful hemodynamic and clinical

Results. Despite the improvement of prostheses design and increasing experience of operators cardiac conduction abnormalities and paravalvular leak continue to be a significant complication of this procedure, directly affecting the long-term prognosis. Self-expanding valves require special approaches for optimal angiographic projection to assess the implantation depth of the prosthesis.

Aims — in this study we compared coplanar view and cusp overlap technique during self-expanding aortic valves implantation.

Methods. We performed a retrospective analysis of 81 TAVI performed in Russian Research Center of Surgery. The patients were divided into two groups depending on the implantation projection: coplanar view (CV) and cusp overlap technique (COT). The incidence of cardiac conduction abnormalities (cumulative incidence of third degree AV block and left bundle branch block) depending on the implantation projection was analyzed. The procedural characteristics in the form of contrast agent volume, fluoroscopic time and operator comfort were also evaluated.

Results. After TAVI 16 (51.6%) and 13 (26.0%) patients had cardiac conduction disturbances (cumulative incidence of third degree AV block and left bundle branch block) in the CV and COT respectively (p = 0.019). In the CV group, 2 (6.5%) patients, and in the COT group, 3 (6%) patients had third degree AV block (p = 0.935) and 14 (45.2%) и 10 (20%) left bundle branch block (p = 0,016). In the COT group, there was a significant decrease contrast media (181 ± 66.4 mL vs. 158.9 ± 50.8 mL, p = 0.032). Fluoroscopic time also decreased (23.2 ± 7.7 min vs. 21.3 ± 6.8 min), but without a significant difference (p = 0.678). According to the results of the operator survey, the COT projection was more comfortable.

Conclusions. Optimal implantation depth is an important condition for achieving hemodynamic efficiency of the prosthesis and reducing the risk of conduction abnormalities. Operator comfort, better assessment of the implantation depth, safety and efficiency of the cusp overlap technique allow its use as the main implantation view for TAVI.

Full Text

Restricted Access

About the authors

Gayk V. Mardanyan

Russian Research Center of Surgery

Author for correspondence.
Email: haikrurg@gmail.com
ORCID iD: 0000-0002-7442-520X
SPIN-code: 2707-0511

MD, PhD

Russian Federation, 2 Abrikosovsky lane, 119991, Moscow

Shota G. Chargazia

Russian Research Center of Surgery

Email: shota.chg@gmail.com
ORCID iD: 0000-0002-8598-2933
SPIN-code: 5965-6158

Clinical Resident

Russian Federation, 2 Abrikosovsky lane, 119991, Moscow

Kiazim A. Kur-ipa

Russian Research Center of Surgery

Email: kuripo90@gmail.com
ORCID iD: 0000-0002-2395-5999
SPIN-code: 1778-4140

Clinical Resident

Russian Federation, 2 Abrikosovsky lane, 119991, Moscow

Roman S. Polyakov

Russian Research Center of Surgery; Russian Medical Academy of Continuing Professional Education

Email: roman.polyakov@gmail.com
ORCID iD: 0000-0002-9323-4003
SPIN-code: 9515-5680

MD, PhD, Professor

Russian Federation, 2 Abrikosovsky lane, 119991, Moscow; 2/1, building 1, Barrikadnaya st., 123242, Moscow

Mikhail V. Puretskiy

Russian Medical Academy of Continuing Professional Education; Russian Research Center of Surgery

Email: 9672287797@mail.ru
ORCID iD: 0000-0003-4988-4102
SPIN-code: 8905-1410

MD, PhD, Professor

Russian Federation, 2 Abrikosovsky lane, 119991, Moscow; 2/1, building 1, Barrikadnaya st., 123242, Moscow

Aleksandra A. Pirkova

Russian Research Center of Surgery

Email: 9672287797@mail.ru
ORCID iD: 0000-0002-5101-1004
SPIN-code: 4024-4326

MD, PhD

Russian Federation, 2 Abrikosovsky lane, 119991, Moscow

Gordey S. Vlasko

Russian Research Center of Surgery

Email: vlasko13@yandex.ru
ORCID iD: 0000-0001-8521-7126
SPIN-code: 9687-2557

PhD, Student

Russian Federation, 2 Abrikosovsky lane, 119991, Moscow

Sergey O. Popov

Russian Research Center of Surgery

Email: Dr.Popov_S@mail.ru
ORCID iD: 0000-0002-4488-1597

MD, PhD

Russian Federation, 2 Abrikosovsky lane, 119991, Moscow

Sergey A. Abugov

Russian Research Center of Surgery; Russian Medical Academy of Continuing Professional Education

Email: sabugov@gmail.com
ORCID iD: 0000-0001-7636-4044
SPIN-code: 1126-8001

MD, PhD, Professor, Corresponding Member of the RAS

Russian Federation, 2 Abrikosovsky lane, 119991, Moscow; 2/1, building 1, Barrikadnaya st., 123242, Moscow

References

  1. Mack MJ, Leon MB, Thourani VH, et al. Transcatheter Aortic-Valve Replacement with a Balloon-Expandable Valve in Low-Risk Patients. N Engl J Med. 2019;380(18):1695–1705. doi: https://doi.org/10.1056/NEJMoa1814052
  2. Popma JJ, Deeb GM, Yakubov SJ, et al. Transcatheter Aortic-Valve Replacement with a Self-Expanding Valve in Low-Risk Patients. N Engl J Med. 2019;380(18):1706–1715. doi: https://doi.org/10.1056/NEJMoa1816885
  3. Sammour Y, Krishnaswamy A, Kumar A, et al. Incidence, Predictors, and Implications of Permanent Pacemaker Requirement After Transcatheter Aortic Valve Replacement. JACC Cardiovasc Interv. 2021;14(2):115–134. doi: https://doi.org/10.1016/j.jcin.2020.09.063
  4. van Rosendael PJ, Delgado V, Bax JJ. Pacemaker implantation rate after transcatheter aortic valve implantation with early and new-generation devices: a systematic review. Eur Heart J. 2018;39(21): 2003–2013. doi: https://doi.org/10.1093/eurheartj/ehx785
  5. Faroux L, Chen S, Muntané-Carol G, et al. Clinical impact of conduction disturbances in transcatheter aortic valve replacement recipients: a systematic review and meta-analysis. Eur Heart J. 2020; 41(29):2771–2781. doi: https://doi.org/10.1093/eurheartj/ehz924
  6. Arnold M, Achenbach S, Pfeiffer I, et al. A method to determine suitable fluoroscopic projections for transcatheter aortic valve implantation by computed tomography. J Cardiovasc Comput Tomogr. 2012;6(6):422–428. doi: https://doi.org/10.1016/j.jcct.2012.10.008
  7. Binder RK, Leipsic J, Wood D, et al. Prediction of Optimal Deployment Projection for Transcatheter Aortic Valve Replacement. Circ Cardiovasc Interv. 2012;5(2):247–252. doi: https://doi.org/10.1161/CIRCINTERVENTIONS.111.966531
  8. Tang GHL, Zaid S, Michev I, et al. “Cusp-Overlap” View Simplifies Fluoroscopy-Guided Implantation of Self-Expanding Valve in Transcatheter Aortic Valve Replacement. JACC Cardiovasc Interv. 2018;11(16):1663–1665. doi: https://doi.org/10.1016/j.jcin.2018.03.018
  9. Rodés-Cabau J, Ellenbogen KA, Krahn AD, et al. Management of Conduction Disturbances Associated With Transcatheter Aortic Valve Replacement. J Am Coll Cardiol. 2019;74(8):1086–1106. doi: https://doi.org/10.1016/j.jacc.2019.07.014
  10. Андерсон Р.Г., Спайсер Д.Е., Хлавачек Э.М., и др. Хирургическая анатомия сердца по Уилкоксу: переулок с англ. / под науч. ред. Г.Э. Фальковского, С.П. Глянцева, Ю.С. Глянцевой. — М.: Логосфера, 2015. — 456 с. [Anderson RG, Spiser DE, Hlavacek EM, et al. Wilcox’s Surgical Anatomy of the Heart. Fal’kovskij GE, Glyancev SP, Glyanceva YuS (eds). Moscow: Logosfera; 2015. 456 p. (In Russ.)]
  11. Kawashima T, Sato F. Visualizing anatomical evidences on atrioventricular conduction system for TAVI. Int J Cardiol. 2014;174(1):1–6. doi: https://doi.org/10.1016/j.ijcard.2014.04.003
  12. Hamdan A, Guetta V, Klempfner R, et al. Inverse Relationship between Membranous Septal Length and the Risk of Atrioventricular Block in Patients Undergoing Transcatheter Aortic Valve Implantation. JACC Cardiovasc Interv. 2015;8(9):1218–1228. doi: https://doi.org/10.1016/j.jcin.2015.05.010
  13. Jilaihawi H, Zhao Z, Du R, et al. Minimizing Permanent Pacemaker Following Repositionable Self-Expanding Transcatheter Aortic Valve Replacement. JACC Cardiovasc Interv. 2019;12(18): 1796–1807. doi: https://doi.org/10.1016/j.jcin.2019.05.056
  14. Moreno R, Dobarro D, López de Sá E, et al. Cause of complete atrioventricular block after percutaneous aortic valve implantation: insights from a necropsy study. Circulation. 2009;120(5):е29–30. doi: https://doi.org/10.1161/CIRCULATIONAHA.109.849281
  15. Petronio AS, Sinning JM, Van Mieghem N, et al. Optimal Implantation Depth and Adherence to Guidelines on Permanent Pacing to Improve the Results of Transcatheter Aortic Valve Replacement with the Medtronic CoreValve System. JACC Cardiovasc Interv. 2015;8(6):837–846. doi: https://doi.org/10.1016/j.jcin.2015.02.005
  16. Thériault-Lauzier P, Andalib A, Martucci G, et al. Fluoroscopic Anatomy of Left-Sided Heart Structures for Transcatheter Interventions. JACC Cardiovasc Interv. 2014;7:947–957. doi: https://doi.org/10.1016/j.jcin.2014.06.002
  17. Cusp Overlap Technique in TAVR. Cardiac Interventions Today. January/February 2021. Available from: https://citoday.com/articles/2021-jan-feb-supplement/cusp-overlap-technique-in-tavr
  18. Maier O, Piayda K, Binnebößel S, et al. Real-world experience with the cusp-overlap deployment technique in transcatheter aortic valve replacement: A propensity-matched analysis. Front Cardiovasc Med. 2022;9:847568. doi: https://doi.org/10.3389/fcvm.2022.847568
  19. Mendiz OA, Noč M, Fava CM, et al. Impact of Cusp-Overlap View for TAVR with Self-Expandable Valves on 30-Day Conduction Disturbances. J Interv Cardiol. 2021;2021:9991528. doi: https://doi.org/10.1155/2021/9991528
  20. Pascual I, Hernández-Vaquero D, Alperi A, et al. Permanent Pacemaker Reduction Using Cusp-Overlapping Projection in TAVR. JACC Cardiovasc Interv. 2022;15(2):150–161. doi: https://doi.org/10.1016/j.jcin.2021.10.002
  21. Баранов А.А., Крестьянинов О.В., Хелимский Д.А., и др. Постоянная электрокардиостимуляция после транскате-терной имплантации самораскрывающихся биопротезов аортального клапана: данные одноцентрового регистра // Патология кровообращения и кардиохирургия. — 2022. — Т. 26. — № 3. — С. 50–63. [Baranov AA, Krestyaninov OV, Khelimskii DA, et al. Permanent pacemaker implantation after transcatheter self-expanding aortic valve replacement: data from a single-center registry. Patologiya krovoobrashcheniya i kardiokhirurgiya = Circulation Pathology and Cardiac Surgery. 2022;26(3):50–63. (In Russ.)] doi: https://doi.org/10.21688/1681-3472-2022-3-50-63
  22. Rexha E, Schlichting A, Chung D, et al. Tick Tock timing of permanent pacemaker implantation after transcatheter aortic valve replacement. A single center review. Europace. 2023;25(Suppl_1). doi: https://doi.org/10.1093/europace/euad122.252
  23. Rodés-Cabau J, Ellenbogen KA, Krahn AD, et al. Management of Conduction Disturbances Associated with Transcatheter Aortic Valve Replacement. J Am Coll Cardiol. 2019;74(8):1086–1106. doi: https://doi.org/10.1016/j.jacc.2019.07.014

Supplementary files

Supplementary Files
Action
1. JATS XML
Download
2. Fig.1. Error bars for the incidence of cardiac conduction disturbances (A) in the form of 3rd degree AV block (B) and complete left bundle branch block (C) after TIA using 3CT and SOT

Download (180KB)
Indexing metadata
3. Fig.2. Error bars for contrast agent used (A), scanning time (B) for TIAC using 3ST and SOT

Download (136KB)
Indexing metadata
4. Fig.3. Anatomical features of the relative position of the conduction system of the heart and the aortic valve: 1 - non-coronary cusp; 2 - septal leaflet of the tricuspid valve; 3 - aorta; 4 — area of the removed membranous septum; 5 - left coronary cusp; 6 - aortic cusp of the mitral valve; 7 - opening of the tricuspid valve; bracket - location of the left ventricular outflow tract; asterisk - transverse sinus of the pericardium; the dotted line on the left side of the figure is the area separating the aortic root from the transverse sinus; a line of triangles is the site of penetration of the His bundle; the dotted line on the right side of the picture is the right fibrous triangle

Download (228KB)
Indexing metadata
5. Fig.4. A – MSCT angiography of the aortic valve in the projection of the three leaflets; B — three-dimensional reconstruction of the aortic valve root in the projection of the three leaflets; red marker corresponds to the non-coronary cusp, purple to the right coronary cusp, yellow to the left coronary cusp

Download (141KB)
Indexing metadata
6. Fig.5. A — MSCT angiography of the aortic valve in the projection of the overlapping leaflets; B — three-dimensional reconstruction of the aortic valve root in the projection of the overlapping leaflets; red marker corresponds to the non-coronary cusp, purple to the right coronary cusp, yellow to the left coronary cusp

Download (137KB)
Indexing metadata
7. Fig.6. Implantation of the Corevalve Evolut R valve, angiography in the projection of the overlapping leaflets (A) and the projection of the three leaflets (B)

Download (189KB)
Indexing metadata
